倍福BECKHOFF EL9410

EL9410 | Power supply terminal for E-bus, with diagnostics

The EL9410 power supply terminal is used to refresh the E-bus. Data is exchanged between the coupler and the EtherCAT Terminal over the E-bus. Each terminal draws a certain amount of current from the E-bus (see “current consumption E-bus” in the technical data). This current is fed into the E-bus by the relevant coupler’s power supply unit. In configurations with a large number of terminals it is possible to use the EL9410 in order to supply an extra 2 A to the E-bus. The EL9410 has a diagnostic function which is displayed by LED and on the process image.

EL9410|E总线电源端子，带诊断

EL9410电源端子用于刷新E总线。耦合器和EtherCAT终端之间通过E总线交换数据。每个终端从E总线中汲取一定量的电流（请参阅技术数据中的“电流消耗E总线”）。该电流通过相关耦合器的电源单元馈入E总线。在具有大量端子的配置中，可以使用EL9410为E总线提供额外的2A。EL9410具有诊断功能，该功能由LED和过程图像显示。

倍福BECKHOFF EL9410 文章出自长欣工控转载请附上链接
